Indoor Air Quality (IAQ) Monitoring
AM107 is a comprehensive IAQ sensor for detecting CO2 concentration, temperature, humidity, light, TVOC, barometric pressure, and motion.
With province-wide LoRaWAN® IAQ solution deployment, students and staff in Quebec's public schools are now in a healthier learning environment with more helpful insights. Check how Milesight has made it happen!
Learn MoreAt Milesight, we help you and your people to live in a safer and healthier facilities.
Towards that end, real-time data about air quality is essential. And that starts with
our one-stop solution for indoor air quality (IAQ)
When PIR value is 0 (Vacant) and last for 20 mins, the screen will stop updating to save power.
2 × 1.5V AA Alkaline Batteries
Switching on/off and configuring the device via NFC technology from a mobile phone or PC
Install the Milesight ToolBox.
Enable NFC and run ToolBox
Attach your phone to the device.
Verify the password and
start configuring.
Wall Mounting
| Wireless Transmission | |
|---|---|
| Technology | LoRaWAN® |
| Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923 |
| Tx Power | 16dBm(868 MHz)/20dBm(915 MHz)/19dBm(470 MHz) |
| Sensitivity | -137dBm @300bps |
| Mode | OTAA/ABP Class A |
| Temperature | |
| Range | -20°C to + 70°C |
| Accuracy | 0°C to + 70°C (+/- 0.3°C), -20°C to 0°C (+/- 0.6°C) |
| Resolution | 0.1°C |
| Humidity | |
| Range | 0% to 100% RH |
| Accuracy | 10% to 90% RH (+/- 3%), below 10% and above 90% RH (+/- 5%) |
| Resolution | 0.5% RH |
| PIR | |
| Detection Area | 94 ° Horizontal, 82 ° Vertical |
| Detection Distance | 5 m |
| Output Range | 0-65535 |
| Light | |
| Range | 60000 lux (Visible + IR, IR) |
| Accuracy | ±30% |
| Carbon Dioxide (CO2) | |
| Range | 300 - 1100 hPa (-40°C - 85°C) |
| Accuracy | ±1 hPa |
| Resolution | 0.1 hPa |
| TVOC | |
| Range | 0 - 60000 ppb |
| Accuracy | ±15 % |
| Resolution | 1 ppb |
| Long-term Stability | 1.3 % accuracy drift per year |
| Barometric Pressure | |
| Range | 300 - 1100 hPa (-40°C - 85°C) |
| Accuracy | ±1 hPa |
| Resolution | 0.1 hPa |
| Display & Configuration | |
| Display | 2.13-inch Dark & Light E-Ink Screen |
| Configuration | 1.Mobile App via NFC 2.PC software via NFC or USB Type-C port |
| Physical Characteristics | |
| Power Supply | 2 × 1.5V AA Alkaline Batteries or Type-C Port |
| Battery Life | Around 1 Year |
| Operating Temperature | 0°C to +45°C |
| Relative Humidity | 0% to 100% (non-condensing) |
| Ingress Protection | IP30 |
| Dimension | 105 × 70.4 × 21.2 mm (4.1 × 2.8 × 0.8 in) |
| Installation | Wall Mounting |
| Approvals | |
| Regulatory | CE, FCC, RoHS, LoRaWAN® Certified |
| EMC | EN 55032, EN 55035 |
| EMS | IEC 61000-4-2 Level 3 IEC 61000-4-3 Level 2 IEC 61000-4-4 Level 4 IEC 61000-4-5 Level 3 IEC 61000-4-6 Level 3 IEC 61000-4-8 Level 4 |
| Radio Frequency | FCC Part 15B, FCC Part 15.247, EN 300 330,EN 301 489-1/3, EN 300 220-1/2 |
| Safety | EN62368-1 |
