Ultimate Companion for Signal Assessment and Optimization
The Milesight Field Tester FT101 is the ultimate companion for signal assessment and optimization in LoRaWAN® networks. Featuring a 5.72-inch HD touch screen, it provides real-time network signal testing and analysis at your fingertips, making it easier to deploy and manage LoRaWAN® devices.
With a 5.72-inch HD touch screen, Milesight Field Tester FT101 displays an immediate assessment of key metrics like RSSI, SNR, and packet loss rate between the gateway and nodes. These insights help you quickly assess the quality of the LoRaWAN® Network and find the best places to deploy LoRaWAN® devices.
Assess RSSI and SNR of the signal
Map your network to understand the areas the gateway covers, providing insights into signal reach
Identify the best locations to set up sensors
Explore the signal strength of the LoRaWAN® Gateway in different locations
Understand how each gateway performs, the area it covers, and the quality of the signal it provides
Understand the impact of physical structures, such as freezers, equipment cabinets, and sewers
Users can effortlessly configure LoRaWAN® settings of the FT101, allowing them to identify the optimal signal configurations
By swapping out external antennas of different frequency bands, FT101 enables comprehensive signal testing across all bands.
CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4
*Note: The standard package includes only one antenna specific to the selected frequency. Additional antennas are optional.
FT101 supports recording the longitude and latitude of location points, enabling users to log signal detection results for each specific location and find optimal network performance across various deployment points.
*Note: Geolocation information is available when used outdoors.
The Milesight Field Tester goes beyond real-time testing by providing a comprehensive report export. With USB Type-C port, you can effortlessly transfer data to your computer for in-depth analysis.
USB Type-C
FT101 is designed for seamless compatibility, supporting all standard LoRaWAN® gateways.
Based on an Android platform, the FT101 allows installation of the Milesight ToolBox app to configure Milesight sensors via NFC easily.
FT101 delivers exceptional battery life, providing up to 8 hours of continuous operation during active testing and up to 7 days on standby. This reliability ensures uninterrupted performance for extended field deployments.
4300mAh
Type-C Charging
| Display | |
|---|---|
| Screen | 5.72-inch TP LCD Touch Screen |
| Resolution | 1440 x 720 Pixels |
| Hardware System | |
| CPU | Octa-core MTK6762, 2 GHz |
| Memory | 4GB RAM + 64GB ROM |
| Operating System | Android 12.0 |
| NFC | Support ISO/IEC 14443A Protocol, Reading Distance: 1-3cm |
| Extendable Storage | 1 × Micro SD Slot Support up to 256G |
| LoRaWAN® | |
| Channel | 1 |
| Antenna Connector | 1 × 50 Ω SMA Female Connector |
| Frequency Band | CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4 |
| Sensitivity | -137dBm@125kHz, SF=12 |
| Max Output Power | 19dBm (470 MHz) /16dBm (868 MHz)/22dBm (915 MHz) |
| Protocol | LoRaWAN® V1.0.3 |
| Work Mode | OTAA Class A |
| Configurable Parameter | Frequency Channel, ADR, Spreading Factor, Tx Power |
| Interfaces | |
| Wi-Fi | IEEE 802.11 b/g/n, 2.4 GHz IEEE 802.11 a/n/ac, 5 GHz |
| Bluetooth | Bluetooth 4.0 (BLE) |
| Cellular | SIM Card Slot: 1 × Nano SIM Frequency Bands: LTE FDD: B1/B3/B5/B7/B8/B20 LTE TDD: B38/B39/B40/B41 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8 |
| GNSS | GPS/Glonass/Beidou/Galileo |
| Rear Camera | 13MP, Autofocus with Flashlight |
| Speaker | 8Ω/0.8W |
| Microphone | Sensitivity -42db, Output Impedance 2.2kΩ |
| USB | 1 x USB 3.0 Type-C Port for Power & OTG |
| Physical Characteristics | |
| Power Supply | 1. Built-in 4.3V/4300mAh Lithium-iron Chargeable Battery 2. 5V⎓2A by USB Type-C |
| Battery Life | Around 8 Hours (Standby Mode: >300h) |
| Operating Temperature | -10°C - 50°C |
| Storage Temperature | -20°C - 60°C |
| Relative Humidity | 95% (Non-condensing) |
| Color | Black |
| Dimension | 178 × 83 × 17 mm (7 × 3.26 × 0.67 in) |
| Weight | 242 g (Without Antenna) |
